qWhen Warning Beep is Activated
The system n otifies the driver of an abnormality by activating the beep sound.
Beep How to check
The beep sound is not heard.
The system may have a malfunction. Have the vehicle inspected at an Authorized
Mazda Dealer as soon as possible.
1 consecutive beep Corner Left Sensor
Remove any foreign material from the sensor area. If
the system does not recover, have the vehicle
inspected at an Authorized Mazda Dealer.
2 consecutive beeps Left Sensor
3 consecutive beeps Right Sensor
4 consecutive beeps Corner Right Sensor
Corner right sensor
Corner left sensor
Right sensor
Left sensor
5-44
Driving Your Mazda
Starting and Driving
