Fully Automatic Type
Climate control information is displayed on the information display.
Temperature setting display (driver)
Ambient temperature /Temperature
setting display (front passenger)
Mode selector display
Airflow display
A/C
DUALAUTO
Air intake display
Information display
Passenger temperature control dial
Windshield defroster switch
Fan control dialDriver temperature control dial
Rear window defroster switch
Air intake selector
OFF switchAUTO switch
Mode selector switch
A/C switch
DUAL switch
OUTSIDE (Ambient
temperature) switch
