Fully Automatic Type (Rear)
Mode selector display
Rear airflow display
AUTO
Fan control switch
Temperature control
switch
OFF switch
Mode selector switch
AUTO switch
AUTO switch
REAR switch
Front
Rear
SYNC
Temperature setting display
qControl Switches
Rear switch
Press the rear switch to operate the rear air
conditioning.
The indicator illuminates to indicate that
the rear air conditioning is operating.
AUTO switch
By pressing the AUTO switch the
following functions will be automatically
controlled in accordance with the set
temperature:
l
Airflow temperature
6-14
Interior Comfort
Climate Control System
