Supplemental Restraint System Components
Driver/Front passenger inflators and air bags
Crash and roll-over sensor, and diagnostic module (SAS unit)
Front seat belt pretensioner and load limiting systems (page 2-25)
Front air bag sensor
Side crash sensors
Air bag/front seat belt pretensioner system warning light (page 2-64)
Side and curtain inflators and air bags
Front passenger air bag deactivation indicator light (page 2-68)
Front passenger seat weight sensors (page 2-68)
Front passenger seat weight sensor control module
Driver and front passenger seat belt buckle switches (page 2-72)
Driver seat slide position sensor (page 2-68)
NOTE
- are equipped only on models with the driver and front passenger occupant classification
system.
2-60
Essential Safety Equipment
SRS Air Bags
