qNormal Head Restraints
Height adjustment
To raise a head restraint, pull it up to the
desired position.
To lower the head rest raint, press the stop-
catch release, then push the head restraint
down.
Adjust the head restraint so that the center
is even with the top of the passenger's
ears.
Front outboard seat
Second-Row outboard seat/Third-Row
outboard seat
Second-Row center seat
Removal/Installat ion
To remove the head restraint, pull it up
while pressing the stop-catch.
To install the head restraint, press the
uprights into the holes while pressing the
stop-catch.
WARNING
Always drive with the head restraints
set up when seats are being used and
make sure they are properly set up:
Driving with the head restraints not
set up is dangerous. With no support
behind your head, your neck could be
seriously injured in a collision.
2-16
Essential Safety Equipment
Seats
