Black plate (439,1)
qArmrest Box
í
To open, pull the release catch.
qCargo Securing Loops
WARNING
Make sure luggage and cargo are
secured before driving:
Not securing cargo while driving is
dangerous as it could move or be
crushed during sudden braking or a
collision and ca use injury.
Use the loops in the luggage compartment
to secure cargo with a rope or net. The
tensile strength of the loops is 196 N (20
kgf, 44 lbf). Do not apply excessive force
to the loops as it will damage them.
qCargo Sub-Compartment
Center cargo sub-compartment
1. Lift the trunk board.
2. Secure the trunk board using the straps
on the third-row seatbacks.
Interior Comfort
Interior Equipment
6-175
í
Some models.
CX-9_8CM9-EA-12I_Edition1 Page439
Thursday, September 13 2012 2:39 PM
Form No.8CM9-EA-12I
