qReplacing Interior Light Bulbs
Overhead light (Front)/Map lights,
Overhead light (Center, Rear ), Luggage
compartment light, Courtesy lights,
Vanity mirror lights
1. Wrap a small flathead screwdriver with
a soft cloth to prevent damage to the
lens, and then remove the lens by
carefully prying on the edge of the lens
with the flathead screwdriver.
2. Disconne ct the bulb by pulling it out.
Overhead light (Front)/Map lights
Overhead light (Center, Rear )
Luggage compartment light
Courtesy lights
Vanity mirror lights
3. Install the new bulb in the reverse order
of the removal procedure.
