DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
16 ABS (SOL) 30 A ABS
17 D/L 25 A Power door locks
18 ROOM 15 A Overhead light
19 OUTLET CTR 15 A Accessory socket (Center)
20 OUTLET RR 15 A Accessory socket (Rear)
21 AC PWR 15 A Moonroof
í
, DC/AC inverter
í
22 S.WARM 15 A Seat warmer
í
23 A/C MAG 10 A Air conditioner
24 BOSE 25 A Audio system (Bose
®
Sound System-equipped model)
í
25 FAN 2
30 A
í
Cooling fan
40 A
í
26 ABS 50 A ABS
27 IG COIL 25 A Engine control system
28
H/L L
*1
15 A Headlight (LH)
H/L LOW L
*2
15 A Headlight low beam (LH)
29
―
*1
――
H/L LOW R
*2
15 A Headlight low beam (RH)
30
―
*1
――
H/L HIGH
*2
20 A Headlight high beam
31 HAZARD 15 A Hazard warning flashers, Turn signal lights
32
10 A Engine control system
33 HORN 15 A Horn
34 STOP 7.5 A Brake lights
35 EGI INJ 10 A Engine control system
36 ENG BAR 20 A Engine control system
37 ENG BAR 2 7.5 A Engine control system
*1 With xenon fusion headlights
*2 With halogen headlights
