Mazda L8 - Electrical System Overview

GI–10
ELECTRICAL SYSTEM
ELECTRICAL PARTS
A6E201700006E01
Battery cable
• Before disconnecting connectors or removing
electrical parts, disconnect the negative battery
cable.
Wiring Harness
• To remove the wiring harness from the clip in the
engine room, pry up the hook of the clip using a
flathead screwdriver.
End Of Sie
CONNECTORS
A6E201700006E02
Data link connector
• Insert the probe into the terminal when
connecting a jumper wire to the data link
connector.
Caution
•
••
•
Inserting a jumper wire probe into the
data link connector terminal may damage
the terminal.
Disconnecting connectors
• When disconnecting connector, grasp the
connectors, not the wires.
