INSPECTION DURING REMOVAL, DISASSEMBLY
A6E201400004E08
• When removed, each part should be carefully
inspected for malfunction, deformation, damage,
and other problems.
End Of Sie
ARRANGEMENT OF PARTS
A6E201400004E09
• All disassembled parts should be carefully
arranged for reassembly.
• Be sure to separate or otherwise identify the parts
to be replaced from those that will be reused.
End Of Sie
CLEANING OF PARTS
A6E201400004E10
• All parts to be reused should be carefully and
thoroughly cleaned in the appropriate method.
Warning
•
••
•
Using compressed air can cause dirt and
other particles to fly out causing injury to
the eyes. Wear protective eye wear
whenever using compressed air.
End Of Sie
REASSEMBLY
A6E201400004E11
• Standard values, such as torques and certain
adjustments, must be strictly observed in the
reassembly of all parts.
• If removed, these parts should be replaced with
new ones:
— Oil seals
— Gaskets
— O-rings
— Lockwashers
— Cotter pins
— Nylon nuts
