When Driving
Instrument Cluster and Display
Warning/Indicator Lights
Instrument Cluster varies depending on model and speci¿ cations.
Instrument Cluster
Center of Dashboard
Warning/Indicator lights will appear in any of the highlighted areas
Warning Lights
These lights turn on or À ash to notify the user of the system operation status or a system
malfunction.
Signal Warning Lights Page
Master Warning Light
*1
7-33
Brake System Warning Light
*1*2
7-33
Electric Vacuum Pump Warning Light
*1
7-33
ABS Warning Light
*1
7-33
Charging System Warning Light
*1
7-33
Engine Oil Warning Light
*1
7-33
