Mazda mx-5 2016 - Vent Operation

5 – 3
Interior Features
Climate Control System
Vent Operation
Adjusting the Vents
Directing airÀ ow
To adjust the direction of airÀ ow, move the
adjustment knob.
N O T E
When using the air conditioner under
humid ambient temperature conditions,
the system may blow fog from the vents.
This is not a sign of trouble but a result of
humid air being suddenly cooled.
Center vents (driver) and Side vents
Air vent open/close
N O T E
The air vents can be fully opened and
closed by operating the knob.
Open
Close
Knob
AirÀ ow direction adjustment
Knob
Center vents (front passenger)
Air vent open/close
OpenClose
Knob
AirÀ ow direction adjustment
Knob
