MB 900 - Offset Multiplier for Bends

-- 11 --
TABLE FOR OFFSET MULTIPLIER
Degree
of
Bend
Multiplier
Degree
of
Bend
Multiplier
1
57.30
25
2.37
2
28.65
26
2.28
3
19.11
27
2.20
4
14.33
28
2.13
5
11.47
29
2.06
6
9.57
30
2.00
7
8.21
31
1.94
8
7.18
32
1.89
9
6.39
33
1.84
10
5.76
34
1.79
11
5.24
35
1.74
12
4.81
36
1.70
13
4.45
37
1.66
14
4.13
38
1.62
15
3.86
39
1.59
16
3.63
40
1.56
17
3.42
41
1.52
18
3.24
42
1.49
19
3.07
43
1.46
20
2.92
44
1.44
21
2.79
45
1.41
22
2.67
46
1.39
23
2.56
47
1.37
24
2.46
48
1.35
DISTANCE BETWEEN BENDS = OFFSET MULTIPLIER FOR
DEGREE X OFFSET HEIGHT
EXAMPLE:
FIND THE DISTANCE BETWEEN BENDS FOR A
15 INCH OFFSET USING 25 DEGREE BENDS.
DISTANCE BETWEEN BENDS = 2.37 X 15 = 35.55 OR 35 9/16
