Connection of a booster battery to
the positive battery terminal on the
tractor
IMPORTANT: When connecting a booster battery to the
tractor positive terminal, make sure the batteries are the
same voltage (i.e. 12 Volt) and the electrolyte is at the cor-
rect level. DO NOT connect auxiliary battery cables across
the terminals of the starter. Always start the engine from
the operator's seat.
WARNING: Always connect the ground cable
last and disconnect the ground cable first
so you do not cause a spark at the battery.
A spark can cause a battery explosion and
cause injury.
Procedure
OPERATION1
Positionthemachinewiththeboosterbatterynexttothe
tractorsothattheboostercablescanbeconnectedeas-
ily.MAKESURETHEMACHINESARENOTTOUCHING.
OPERATION2
Removetheredcapfromthepositiveterminal(1).
Connect the booster battery positive (+) to the
tractor positive terminal (+) and the negative (-)
to a good ground on the tractor frame, not to the
tractor battery terminal.
OPERATION3
Starttheengineofthemachinewiththeboosterbattery
andruntheengineforapproximately2minutes.
OPERATION4
Start the tractor engine. See correct procedure in this
manual.
OPERATION5
Whenthetractorenginehasstarted,disconnectthenega-
tiveboostercablefromthetractorframeandthebooster
battery negative first, then the positive cable from the
tractorterminalandtheboosterbattery.
Installtheredcaponthepositiveterminalafterthestart-
ingoperationhasbeencompleted.(Thepositionofthe
terminaldependsontractormodel)
WARNING: Always use specific personal safety devices
for each operation.
