McCulloch 967059700 - Product Overview

1.2 Product overview
1
2
3
5
16
17
6
18
19
21
20
10
9
8
7
11
12
13
27
15
14
25
26
24
23
22
4
The numbers in the illustration represent:
1. Body
2. Cover to display, keypad and cutting height
adjustment
3. Stop button
4. Contact strips
5. LED for operation check of the charging
station, boundary wire and guide wire
6. Charging station
7. Carry handle
8. Battery cover
9. Blade disc
10. Chassis box with electronics, battery and
motors
11. Main switch
12. Rear wheel
13. Charging strip
14. Keypad
15. Display
16. Loop wire for boundary loop and guide wire
17. Low voltage cable
18. Connector for connecting the loop wire to
the charging station
4 - Introduction 1054 - 001 -
