English – 27
TECHNICAL DATA
1154654-27 Rev.3 2013-03-11
Recommended cutting equipment for USA
Following is a list of recommended cutting equipment for McCulloch chain saw model CS 380. This chainsaw model
equipped with either of the listed bar and saw chain combination(s), fulfills the requirements according to ANSI B175.1-
2000 (Gasoline Powered Chain Saws - Safety Requirements).
The following list is the chain saw manufacturers recommendations. There may be other combinations available, which
will also achieve kickback reduction.
Chain saw model McCulloch CS 380 met the kickback performance requirements of ANSI B 175.1-2000 when tested
with the combinations of bars and saw chains listed below. The saw chains McCulloch H37, Husqvarna H37 and Oregon
91PX are also classified as a low kickback saw chain since they met the requirements for low kickback saw chain outlined
in ANSI B 175.1-2000. We recommend to use only the listed combinations of bars and chains for chain saw model
McCulloch CS 380. Other chain saw models may not meet the kickback requirements when equipped with the listed bar
and chain combinations.
Recommended cutting equipment for Canada
Following is a list of recommended cutting equipment for the McCulloch chain saw model CS 380. The listed
combination(s) of powerhead, bar and saw chain meet all requirements outlined in Canadian Standards Assosiation
Z62.1-03 (Chain Saws) and Z62.3-04 (Chain Saw Kickback).
Furthermore the saw chains McCulloch H37, Husqvarna H37 and Oregon 91PX are evaluated and listed as Type C Low
Kickback Saw Chains according to the provisions in Z62.3-04.
Kickback information
The guide bar nose radius is determined by either the maximum number of teeth in the nose sprocket or the
corresponding maximum nose radius of a solid bar.
As we are listing the maximum guide bar nose radius, you may use a guide bar with smaller nose radius than in our list.
For guide bars of the same length, all sprocket-nose guide bars of the same pitch and having the same number of
sprocket teeth may be considered to have equivalent kickback energy.
The following cutting attachments are approved for the model McCulloch CS 380.
Saw chain filing and file gauges
Guide bar Saw chain
Length, inch Pitch, inch Gauge, inch Max. nose radius Type Drive link count
14
3/8 0.050 7 T
McCulloch H37,
Husqvarna H37,
Oregon 91PX
52
16 56
18 62

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the McCulloch CS 340 and is the answer not in the manual?

McCulloch CS 340 Specifications

General IconGeneral
Chain gauge1.27 mm
Chain pitch3/8 \
Chain speed20 m/s
Product colorBlack
Chain bar length400 mm
Oil tank capacity0.2 L
Fuel tank capacity0.25 L
Engine displacement34.4 cm³
Noise level102 dB
Vibration emission5.3 m/s²
Power sourceGasoline
Weight and Dimensions IconWeight and Dimensions
Weight5200 g
