TECHNICAL DATA
1154654-27 Rev.3 2013-03-11
Technical data
CS 380
Motor
Cylinder displacement, cu.in/cm
3
2.3/38
Stroke, inch/mm 1.26/32
Idle speed, rpm 3000
Power, KW/hp @ rpm 1.4/1.9 @ 9000
Emissions Durability Period according to California Air
Resources Board, h.
125
Ignition system
Spark plug Champion RCJ 7Y
Electrode gap, inch/mm 0.020/0,5
Fuel and lubrication system
Fuel tank capacity, US pint/litre 0.53/0,25
Oil pump capacity at 8,500 rpm, ml/min 7
Oil tank capacity, US pint/litre 0.43/0,20
Type of oil pump Automatic
Weight
Chain saw without bar or chain, empty tanks, lb/kg 11.4/5,2
Chain/bar
Standard bar length, inch/cm 18/45
Recommended bar lengths, inch/cm 14/35, 16/40, 18/45
Usable cutting length, inches/cm 13/33, 15/38, 17/43
Chain speed at max. power, m/sec 20,0
Pitch, inch/mm 3/8" /9,52
Thickness of drive links, inch/mm 0.050/1,3
Drive sprocket type/teeth Spur/6

McCulloch CS 340 Specifications

General

Chain gauge	1.27 mm
Chain pitch	3/8 \
Chain speed	20 m/s
Product color	Black
Chain bar length	400 mm
Oil tank capacity	0.2 L
Fuel tank capacity	0.25 L
Engine displacement	34.4 cm³
Noise level	102 dB
Vibration emission	5.3 m/s²
Power source	Gasoline

Weight and Dimensions

Weight	5200 g
