McGuire TPR - Periodic Maintenance

25
MAINTENANCE
Daily Maintenance
• Verify that all inside and outside signal lights and
alarm (if equipped) work correctly.
Weekly Maintenance
• Operate the vehicle restraint through the complete
operating cycle to maintain lubrication.
• Remove debris around UniLock vehicle restraint
and in roller track.
• Verify carriage assembly is able to move up and
down freely with no binding or obstruction.
• Inspect motor and spring covers.
• Inspect latch barrier blocks for wear or damage;
replace as needed.
• Inspect latch plates and retaining ring on pivot pin
for damage or wear.
• Inspect latch plates and verify they rotate without
binding or obstructions. DO NOT lubricate the latch
plates.
• Inspect warning decals and placards. Replace if
damaged or missing
Periodic Maintenance
Quarterly Maintenance
• Complete Weekly Maintenance.
• Inspect the following for damage/abnormal wear:
• Check welds for cracks.
• Check motor mount bolts.
• Pivot pins and mounting holes.
• Check J-box for water damage.
• Control box and conduit for damage.
• Light bulbs and lenses.
• Bumpers for more than 1” of wear. Replace
worn, loose, damaged or missing bumpers.
• Lubricate the rollers at the fittings located on the
top and bottom axle with a synthetic oil-base moly
grease with a temperature range of –40° to 170° F.
• Lubricate the hook weldment at the tting with a
synthetic oil-base moly grease with a temperature
range of –40° to 170° F.
• Remove retaining ring, remove pivot pin and latch
plates, clean off dirt debris and other foreign matter
from the assembly and mating surfaces. Reinstall
parts; verify parts are moving freely without binding
or obstruction. DO NOT lubricate the latch plates.
• Inspect chain tension, verify 1/8-1/4 inch of play.
• Lubricate drive chain and limit switch mounting
bracket between drive sprocket and cam with a
synthetic oil-base moly grease with a temperature
range of –40° to 170° F.
• Verify brake torque is greater than 42 ft-lbs and
less than 58 ft-lbs at the hook shaft, while rotating the
hook from ENGAGED (45 deg) to STORED.
• Check that all concrete anchor bolts are torqued
to 60 ft-lbs.
