27
ADJUSTMENTS
Figure 20
LOCKNUT
BRAKE ADJUSTER SET SCREW
USE TORQUE WRENCH
LUBRICATE DRIVE CHAIN AND LIMIT
SWITCH MOUNTING BRACKET. USE
SPRAY GREASE (ZEP 2000 OR EQUAL)
Figure 19
45 DEGREES
96 IN-LBS
4111-0073 — Sept. 2018
© 2018 Systems, LLC
