McGuire TPR - Page 37

35
UniLock Carriage Assembly (continued)
PARTS
Item Quantity Part Number Description
1 1 9701-0237 Hook Cam Shaft
2 3 2101-0321 Screw,HHCS,5/16-18 X 5/8”
3 1 9701-0200 Ring, Snap
4 4 9701-0113 Roller Assembly
5 1 9701-0201 3/4” Conduit Nipple
6 1 0961-0570 Limit Switch, LS1
7 1 0961-0571 Limit Switch, LS2
8 1 9701-0247 Cam
9 2 9701-0111 Bearing Assembly
10 1 9701-0202 DECAL, CAM
11 1 9701-0109 Limit Switch Mounting Plate
12 1 9701-0244 Chain Cover
13 2 9701-0203 Lock Nut 7/16”-14 Serrated Flange
14 8 9701-0204 Nut, Lock 3/8”-16 Serrated Flange
15 2 9701-0205 Cap Screw 1/4”-20 x 1-1/2” Socket Head
16 1 2101-0039 Nut, Nylon Lock , 5/16-18 UNC
17 1 2101-0327 Screw, HHCS, 5/16-16 UNC x 3.75 GR5
18 2 2101-0005 Washer, Lock 1/4”
19 1 1751-0149 Decal, No Step
20 1 9701-0207 Key, Hook 1/4” x 1/4” x 1-1/4”
21 2 9701-0208 Key, Sprocket/Cam 1/4” x 1/4” x 1”
22 1 9701-0110 Hook Shaft
23 2 9701-0209 Nut, Lock 3/4” Conduit
24 1 9701-0114 Drive Sprocket,Hook w/Set Screw
26 8 9701-0211 Bolt, Carriage 3/8”-16 x 1”
27 1 9701-0212 Cord Grip
28 1 9703-0022 Hook Weldment, UniLock
29 1 9701-0106 Carriage Weldment
30 1 4301-0008 Wire Harness
31 1 9701-0115 Chain
32 1 3411-0050 Motor Assembly
33 1 1751-1104 Decal, Product
34 1 0521-0201 Fitting, Grease Zerk,1/8 NPT
35 1 1751-0010 Decal, Serial
36 1 1751-1105 Decal, UniLock Stripe RH
37 1 1751-1106 Decal, UniLock Stripe LH
38 4 2101-0339 Screw,HHCS-1/2-13UNC x 1.00 GR8
39 2 9701-0215 Grease Fitting
40 1 9201-0007 Pin, Dowel, Steel
41 2 9701-0253 Latch Barrier Block
42 2 2101-0010 Bolt, 5/16-18 x 7/8 LG
43 4 2101-0322 Screw,SHSS,1/4-28 UNF x 1/4 Socket Cup
44 2 9701-0248 Latch Plate
45 1 9701-0304 Pin, Pivot with Retaining Ring Groves
46 2 2101-0333 Ring, Retainer 3/4 DIA. External
47 6 2101-0034 Screw, FHCS, 1/4-20 UNC X 3/4
48 1 9701-0238 Hook Cam Cover UniLock
49 2 2101-0033 Screw,SHSS, 1/4-20 UNC X 3/8
50 4 2101-0079 Washer, Flat 1/2”
