McHale 991B Round Bale Wrapper
11
2.3 General dimensions & specifications
Units are given in both metric and UK imperial values, with the latter shown in brackets.
Check with national road traffic regulations in the individual country!
2.4 Tractor attachment
2.5 Machine specifications
Transport length 5.7 m (18’ 8”)
Transport width 2.45 m (8’ 0”)
Transport height 2.46 m (8’ 1”)
Height to top of rollers 1.25 m (4’ 1”)
Transport weight (unladen) 1,870 kg (4,123 lbs)
Tyre dimensions 340/55 -16
Tyre pressure 3.4 bar/50 psi
Maximum road speed 40 km/h (25 mph)
Attachment Pin hitch
Towing tractor requirements 35 KW
Electrics 12 Volt DC, 7 amp approx.
Hydraulic systems Load sensing, open centre, closed centre
Minimum hydraulic pressure 170 bar (2,465 psi)
Minimum hydraulic flow rate 22 l/min (4.8 gal/min)
Maximum rotary table speed 30 rpm
Film stretch 70% (64% or 55% optional)
Film layers 2+2 system
Film width 750 mm (500 mm optional)
Maximum bale size 1.50 m (4’ 11”)
Maximum bale weight 1,000 kg (2,205 lbs)
