McHale 991B Round Bale Wrapper
25
4.7 Machine lifting guidelines
991 B series chassis plate
RHS front lift hook Front View LHS front lift hook
RHS rear lift hook Rear View LHS rear lift hook
WARNING: Machine Lifting
Only use chains or strapping that are rated for a minimum load
of 0.75 tonnes (750 kg) per chain or strap when using the four
lift eye locations on the chassis, shown below
The crane or lifting device must be capable of lifting a
minimum load of 2.5 tonnes (2,500 kg)
Never go under a suspended machine or attempt to try and
stop it, if it is moving erratically, death or serious injury may
result
Always be observant of people and objects around the
suspended machine and do not allow the machine to impact
heavily on the ground after suspension or movement
