McIntosh MA6100 User Manual

MA 6100
REPLACEMENT PARTS
All parts not listed are common items obtain-
able from radio parts jobbers.
Replacement parts may be obtained when ordered
by PART NUMBER from:
Mclntosh Laboratory, Inc.
C us tomer Service Department
2 Chambers Street
Binghamton, New York 13903
( telephone 607-723-3512)
Symbol
Number
C101 , 102
C105, 106
C107,108
C111 , 112
C113, 114
C115,116
C119, 120
C123, 124
C125,126
C127, 128
C129, 130
CI31 ,132
C137,138
C201 ,202
C209.210
C212 ,213
C301
C302
C303
C305
C306
C307
C312
C313,314
C317
C401 ,402
C403,404
C419,420
C427,428
D301 ,302
D303,304
D305,306
D307
CAPACITORS
Description
Mylar . 47µF
Ta. Elect 10µF
Ta. Elect 10µF
Mylar . 4µF
Ta. Elect- 100µF
Mylar . 1 µF
Mylar . 22 µF
Ta. Elect 100µF
Mylar .22µF
Mylar . 1 µF
Mylar .022µF
Mylar .01µF
Mylar .47µF
Mylar .22µF
Mylar .01µF
Mylar .022µF
Mylar . 47µF
Ta. Elect 10µF
Elect. 33µF
Mylar .22µF
Mylar 1µF
Elect. 100µF
250V
63V
63V
250V
16V
250V
16V
250V
250V
250V
250V
250V
250V
250V
250V
63V
40V
250V
40V
Elect . 80/150/150/200µF
200/200/150/100V
Elect. 9300µF
Elect. 220µF
Elect. 150µF
Elect. 470µF
Elect. 10µF
Ta. Elect 1.5µF
DIODES
S i . Rect i f i er
S i . Rect i f ier
S i . Rect i fier
Zener
50V
100V
63V
4V
35V
20V
75V
Part
Number
064-069
066-221
066-178
064-069
066-226
064-067
064-068
066-226
064-068
064-067
064-102
064-040
064-069
064-068
064-040
064-102
064-069
066-221
066-204
064-096
064-088
066-206
066-191
066-162
066-201
066-?05
066-136
066-173
066-158
070-041
070-041
070-031
070-025
D417,418
D419,420
0308
D309
D401 ,402
D403,404
D405,406
D407,408
D409,410
D411 ,412
D413,414
D415,416
F401 ,402
F403,404
CB301
L401 ,402
Q101 , 102
Q 103, 104
Q105, 106
Q107, 108
QI09, 110
Ql11 , 112
Ql13, 114
Q115, 116
Q301
Q302
Q303
Q401 ,402
Q403 ,404
Q405,406
Q407,408
Q409,410
Q411 ,412
Q413, 414
Q415,416
Q417 ,418
R20I
R2IO
R21 1
R212
Si. Rectifier
Si. Rectifier
Si. Rectifier
Zener 20V
Si. Rectifier
Si. Rectifier
Si. Rectifier
Si. Rectifier
Si. Rectifier
Si. Rectifier
Ge. PNP Transistor
Si. Rectifier
FUSES
Fuse 5A
Fuse 5A
Circu i t B reaker 4A
CHOKES
Choke 4µH
TRANSISTORS
Si . PNP transi stor
S i . PNP trans istor
S i . NPN trans istor
S i . NPN trans i stor
S i . NPN t rans i stor
S i . NPN trans i stor
S i . NPN transi stor
S i . NPN t rans i s tor
SI. NPN t rans i s tor
S i . PNP trans i stor
S i . NPN trans i stor
S i . PNP trans i stor
Si. PNP trans i stor
Si. NPN t rans istor
S i . NPN trans istor
Si. PNP t rans i stor
Si. NPN transistor
Si . PNP transi stor
S i . NPN t rans istor
S i . NPN trans i stor
POTENTIOMETERS
Ba l ance con t ro l
Vo 1 ume cont ro l
Bass trim con t ro l
Bass trim control
070-046
070-046
070-031
070-064
070-047
070-046
070-047
070-047
070-031
070-031
132-098
070-047
089-014
089-014
088-007
122-105
132-096
132-096
132-095
132-093
132-093
132-093
132-095
132-095
132-094
132-096
132-078
132-056
132-056
132-081
132-021
132-032
132-080
132-079
132-128
132-128
134-240
134-239
134-354
134-254

McIntosh MA6100 Specifications

General

Frequency Response	20Hz to 20kHz
Input Sensitivity	2.5mV (MM), 250mV (line)
Signal to Noise Ratio	75dB (MM), 90dB (line)
Dimensions	14 inches (35.6 cm) deep
Output Impedance	8 ohms
Power Output	70 watts per channel
