5
Dimensions
Dimensions
The following dimensions can assist in determining the
best location for your MA6300. There is additional in-
formation on the next page pertaining to installing the
MA6300 into cabinets.
17-1/2"
44.45cm
7-5/8"
19.37cm
3/16"
0.48cm
17"
43.18cm
Front View of the MA6300
Rear View of the MA6300
Side View of the MA6300
7-1/8"
18.10cm
13/16"
2.06cm
6-5/16"
16.03cm
13-1/4"
33.65cm
18-1/2"
46.99cm
17"
43.18cm
6-1/2"
16.51cm
1-1/4"
3.18cm
12-5/8"
32.07cm
3-1/32"
7.70cm

Table of Contents

Other manuals for McIntosh MA6300

Preview: Service Manual
Service Manual28 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the McIntosh MA6300 and is the answer not in the manual?

McIntosh MA6300 Specifications

General IconGeneral
Amplifier class-
Frequency range20 - 20000 Hz
Audio output channels2.0 channels
Peak power per channel160 W
Signal-to-Noise Ratio (SNR)110 dB
Total Harmonic Distortion (THD)0.005 %
RMS power output per channel (8 Ohm)100 W
XLR inYes
PurposePerformance/stage
Product colorBlack
Connectivity technologyWired
Maximum current5 A
AC input voltage120 V
AC input frequency50 - 60 Hz
Weight and Dimensions IconWeight and Dimensions
Depth558.8 mm
Width444.5 mm
Height193.7 mm
Weight16800 g
