INPUT IMPEDANCE
Phono: 47K ohms and 65pF Capacitance
High Level: 22K ohms
TONE CONTROLS
Bass and Treble, variable 12dB boost to 12dB cut
AC POWER OUTLETS
1 Switched
1 Unswitched
POWER REQUIREMENTS
120 volts. 50/60, Hz. 5 Amps UL/CSA
DIMENSIONS
Front panel, 17-1/2 inches (44.5cm) wide. 5-3/8 inches (13.7cm) high, depth behind front
panel including clearance for connectors, 18-1/8 inches (46cm). Knob clearance required in
front of the mounting panel, 1-1/8 inches (2.9cm).
FINISH
The front panel is all glass, with gold/teal nomenclature illumination. The chassis is black.
WEIGHT
41 pounds (18.6Kg) net, 60 pounds (27.2Kg) in shipping carton.
24
SPECIFICATIONS
