McIntosh MB100 User Manual

22
Specications
Audio Specifications
Digital Audio Specifications
Digital Output
Coaxial: 0.5V p-p/75 ohms
Optical: - 15dbm to -21dbm (TOS Link)
Digital Output Format
SPDIF (PCM
1
)
Digital Output Sample Rate
Up to 24-Bit/192kHz
1
PCM (Pulse Code Modulation) Digital Signal Type
Power Requirements
Field AC Voltage conversion of the MB100 is not
possible. The MB100 is factory configured for fol-
lowing AC Voltages:
100-240 Volts, 50/60Hz at 2.0 Amps
Standby: Less than 0.5 watt
Overall Dimensions
Width is 17-1/2 inches (44.4cm)
Height is 3-7/8 inches (9.8cm)
Depth is 16 inches (40.6cm) including the Front Panel
and connection cables.
Weight
13.5 pounds (6.1Kg) net (includes the external Power
Supply), 28 pounds (12.7Kg) in shipping carton
Shipping Carton Dimensions
Width is 26-1/2 inches (67.3cm)
Height is 11-3/4 inches (29.9cm)
Depth is 24-1/4 inches (62.2cm)
General Specifications
Fixed Output Level
2.0Vrms Unbalanced
4.0Vrms Balanced
Output Impedance
600 ohms Unbalanced and Balanced
Signal to Noise Ratio
102dB (IHF A-Weighted)
Dynamic Range
96dB
Harmonic Distortion
0.005%
Channel Separation
95dB (1,000Hz)
Video Specications
Signal System
Digital Video
Signal Format
HDMI and DVI
Screen Resolution
720p or 1080p
Power Control Input
5-15VDC, less than 1mA
Power Control Output
12VDC, 25mA maximum total
Power Control Specications
