1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install
in accordance with the manufacturer’s instruc-
tions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other appa-
UDWXVLQFOXGLQJDPSOL¿HUVWKDWSURGXFHKHDW
9. Do not defeat the safety purpose of the polar-
ized or grounding-type plug. A polarized plug
has two blades with one wider than the other.
A grounding type plug has two blades and a
third grounding prong. The wide blade or the
third prong are provided for your safety. If
WKHSURYLGHGSOXJGRHVQRW¿WLQWR\RXURXWOHW
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
2QO\XVHDWWDFKPHQWVDFFHVVRULHVVSHFL¿HGE\
the manufacturer.
12. Use only with the cart, stand, tripod, bracket,
RUWDEOHVSHFL¿HGE\WKHPDQXIDFWXUHURUVROG
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus com-
bination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
5HIHUDOOVHUYLFLQJWRTXDOL¿HGVHUYLFHSHUVRQ-
nel. Servicing is required when the apparatus
has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the apparatus has
been exposed to rain or mois-
ture, does not operate normally,
or has been dropped.
15. Do not expose this equipment
to dripping or splashing and ensure that no
REMHFWV¿OOHGZLWKOLTXLGVVXFKDVYDVHVDUH
placed on the equipment.
16. To completely disconnect this equipment from
the a.c. mains, disconnect the power supply
cord plug from the a.c. receptacle.
17. The mains plug of the power supply cord shall
remain readily operable.
18. Do not expose batteries to excessive heat such
DVVXQVKLQH¿UHRUWKHOLNH
19. Connect mains power supply cord only to a
mains socket outlet with a protective earthing
connection.
IMPORTANT SAFETY
INSTRUCTIONS!
PLEASE READ THEM BEFORE
OPERATING THIS EQUIPMENT.
Copyright 2010 © by McIntosh Laboratory, Inc.
Table of Contents
Safety Instructions ..................................................2-3
Table of Contents .......................................................3
Thank You and Please Take a Moment ......................4
Technical Assistance and Customer Service .............4
General Information ..................................................4
Connector and Cable Information .............................4
Disc Information ........................................................5
Introduction ................................................................5
Performance Features ................................................5
Dimensions ................................................................6
Installation .................................................................7
Connections:
Rear Panel Connections ............................................. 8
MCD1100 Connections .............................................10
&RQQHFWLRQ'LDJUDPV6HSDUDWH6KHHW ............. Mc1A
MCD1100 Direct to Power Amplifier Connections ..11
&RQQHFWLRQ'LDJUDP6HSDUDWH6KHHW ............... Mc1B
Front Panel Features:
Front Panel Displays, Controls, Push-buttons
and Jack .....................................................................12
Front Panel Information Displays .............................13
Remote Control:
Remote Control Push-buttons ...................................14
How to use the Remote Control ................................15
Operation:
How to Operate the MCD1100 ..................................16
Additional Information:
Specifications ........................................................... 22
Packing Instruction .................................................. 23
