19
Packing the MCD12000
When shipping the MCD12000, it is highly recom-
mended that the unit be packed as it was originally
shipped to avoid damage. Failure to properly pack
the unit will likely result in damage. (The front panel
is made of glass!) If you need any of the packing
material, you can contact McIntosh Customer Service.
Use only packing material that is in good condition
and replace any material that has seen better days.
It is very important that the four plastic feet are
properly placed in the holes of the Foam Bottom Pad.
This will ensure the proper equipment location for
shipping. Failure to do this will result in shipping
damage.
Quantity Part Number Description
1 033888 Shipping Carton
1 034692 Pad Bottom
1 034691 Foam Top - Inner Carton
1 033697 Inner Box
1 033739 Poly Bag
20" W X 10" D X 36" L
4 034670 End Cap
4 017937 Plastic Foot
4 400159 10-32 X 3/4" Screw
4 404080 #10-7/16" Flat Washer
