McIntosh MCD301 Service Manual

MCD301
5
6
PARTS LIST con’t
35
DISPLAY PCB 750773 (cont’d)
Ref No. Description Part No.
Ref No. Description Part No.
DS1 LED GREEN 5MM HI-INT 058165
(DS1) SPACER LED 112108
DS2 LED GREEN 5MM HI-INT 058165
(DS2) SPACER LED 112108
DS3 FL TUBE 8BT258GINK 310369
DS4 DISPLAY 4 DIGITS DOT MATRIX VFD 058188
DS5 LED RED 5MM ROUND 058187
(DS5) LED SPACER .220 LENGTH 163001
DS6 LED RED 5MM ROUND 058187
(DS6) LED SPACER .220 LENGTH 163001
FN1 FILTER EMI 180057
J1 7 PIN SHROUDED HEADER 117910
J2 CONN 13 PIN FFC 117919
J3 CONNECTOR FFC 8 PIN 117915
J4 CONN FFC 18PIN 117908
L1 BEADS FERRITE LEADED 076023
L2 CHOKE 18UH 5%-10% 122394
L3 BEADS FERRITE LEADED 076023
TAPE FOAM 3/16 THK 1 X 1/2 BLK 094509
BUMPER DOT 1/2 DIA X 1/2 THK 094510
MT1 SENSOR IR 38KHZ 121046
PCB1 PC BD DISPLAY 129869
Q1 TRANSISTOR NPN SILICON 132317
Q2 TRANSISTOR NPN SILICON 132317
Q3 TRANSISTOR NPN SILICON 132317
R1 RES MF 150 OHM 1% 1/4W 144535
R2 RES MF 100 OHM 1% 1/4W 144568
R3 RES MF 150 OHM 1% 1/4W 144535
R4 RES MF 100 OHM 1% 1/4W 144568
R5 RES MF 1K 1% 1/4W 144513
R6 RES MF 1K 1% 1/4W 144513
R7 RES NETWORK 5X47K BUSSED 144499
R8 RES MF 10 OHM 1% 1/4W 144553
R9 RES MF 10 OHM 1% 1/4W 144553
R10 RES NETWORK 4 X 100 ISO 144676
R11 RES NET 10K X8 RES B 144675
R12 RES MF 47.5K 1% 1/4W 144526
R13 RES MF 2.87K 1% 1/4W 144546
R14 RES MF 3.32K 1% 1/4W 144518
R15 RES MF 4.75K 1% 1/4W 144520
R16 RES MF 10 OHM 1% 1/4W 144553
R17 RES NETWORK 4 X 100 ISO 144676
R18 RES MF 47.5K 1% 1/4W 144526
R19 RES NETWORK 5X47K BUSSED 144499
R20 RES MF 8.25K 1% 1/4W 144549
R21 RES MF 8.25K 1% 1/4W 144549
R22 RES MF 8.25K 1% 1/4W 144549
R23 RES MF 8.25K 1% 1/4W 144549
R24 RES MF 8.25K 1% 1/4W 144549
R25 RES MF 8.25K 1% 1/4W 144549
S1 SWITCH PB TACT 150058
S2 SWITCH PB TACT 150058
S3 SWITCH PB TACT 150058
S4 SWITCH PB TACT 150058
S5 SWITCH PB TACT 150058
S6 SWITCH PB TACT 150058
S7 SWITCH PB TACT 150058
S8 SWITCH PB TACT 150058
S9 SWITCH PB TACT 150058
U1 DECIMAL TO BCD ENCODER 133454
C2 CAP MONO .1UF 50V 20% Z5U 061346
C3 CAP MONO .1UF 50V 20% Z5U 061346
C4 CAP MONO .1UF 50V 20% Z5U 061346
DS1 LED GRN 5MM HI-INTENSITY 058165
(DS1) SPACER LED 112108
DS2 LED GRN 5MM HI-INTENSITY 058165
(DS2) SPACER LED 112108
DS3 LED GRN 5MM HI-INTENSITY 058165
(DS3) SPACER LED 112108
J1 CONN 8 PIN FFC 117915
PCB1 PC BD CONTROL 129716
R1 RES MF 100 OHM 1% 1/4W 144568
R2 RES MF 100 OHM 1% 1/4W 144568
R4 RES MF 100 OHM 1% 1/4W 144568
S2 SWITCH ROT ENCODER NO DETENT 146256
S1 ENCODER 11MM SELF-RETURN TYPE 146257
CONTROL PCB 750295
POWER PCB 750772
C1 CAP ELECT 470UF 16V 066508
C2 CAP MONO .1UF 50V 20% Z5U 061346
C3 CAP ELECT 22000UF 16V 066579
C4 CAP MPF 0.033UF 100V 10% 064427
C5 CAP ELECT 100UF 25V 066573
C6 CAP ELECT 47UF 35V 066446
C7 CAP MONO .1UF 50V 20% Z5U 061346
C8 CAP ELECT 47UF 35V 066446
C9 CAP ELECT 3300UF 35V 066509
C10 CAP MPF 0.033UF 100V 10% 064427
C11 CAP ELECT 220UF 50V 20% 066254
C12 CAP ELECT 220UF 50V 20% 066254
C13 CAP MPF 0.033UF 100V 10% 064427
C14 CAP MONO .1UF 50V 20% Z5U 061346
C15 CAP ELECT 22000UF 16V 066579
C16 CAP ELECT 3300UF 35V 066509
C17 CAP ELECT 3300UF 35V 066509
C18 CAP ELECT 3300UF 35V 066509
C19 CAP MONO .1UF 50V 20% Z5U 061346
C20 CAP MONO .1UF 50V 20% Z5U 061346
C21 CAP MONO .1UF 50V 20% Z5U 061346
C22 CAP MONO .1UF 50V 20% Z5U 061346
C23 CAP MONO .1UF 50V 20% Z5U 061346
C24 CAP ELECT 470UF 16V 066508
C25 CAP ELECT 470UF 16V 066508
C26 CAP ELECT 470UF 16V 066508
C27 CAP ELECT 220UF 25V 066507
C28 CAP ELECT 220UF 25V 066507
D1 DIODE ZENER 2.4V 070195
D2 DIODE SILICON 070174
D3 DIODE SIL 400 PIV @ 1.5A 070031
D4 DIODE SIL 400 PIV @ 1.5A 070031
D5 DIODE SIL 400 PIV @ 1.5A 070031
D6 DIODE SIL 400 PIV @ 1.5A 070031
D7 DIODE ZENER 33V 5% 1/2W 070182
D8 DIODE SIL 400 PIV @ 1.5A 070031
D9 DIODE SIL 400 PIV @ 1.5A 070031
D10 DIODE SILICON 070174
D11 DIODE SIL 400 PIV @ 1.5A 070031
D12 DIODE SIL 400 PIV @ 1.5A 070031
D13 DIODE SIL 400 PIV @ 1.5A 070031
D14 DIODE SIL 400 PIV @ 1.5A 070031
D15 DIODE SIL 400 PIV @ 1.5A 070031

McIntosh MCD301 Specifications

General

Frequency range	4 - 40000 Hz
Audio formats supported	MP3
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.002 %
CD-RW playback	Yes
Playback disc formats	CD audio, SACD
CD changer	No
Device type	Personal CD player
Product color	Black
Channels quantity	2 channels
Disc loading type	Tray
Number of optical discs	1 discs
Remote control type	IR

Weight and Dimensions

Depth	419.1 mm
Width	444.5 mm
Height	152.4 mm
Weight	12800 g
