McIntosh MCD301 Service Manual

36
PARTS LIST con’t
POWER PCB 750772 (cont’d)
Ref No. Description Part No.
Ref No. Description Part No.
D16 DIODE SIL 400 PIV @ 1.5A 070031
D17 SCHOTTKY RECTIFIER 5A 100V 070171
D18 SCHOTTKY RECTIFIER 5A 100V 070171
D19 SCHOTTKY RECTIFIER 5A 100V 070171
D20 SCHOTTKY RECTIFIER 5A 100V 070171
D21 DIODE SIL 400 PIV @ 1.5A 070031
F1 FUSE 2A 250V SLO-BLO 5X20 IEC 089123
(F1) HOLDER FUSE 5X20MM PCB MOUNT 178159
F2 FUSE 2A 250V SLO-BLO 5X20 IEC 089123
(F2) HOLDER FUSE 5X20MM PCB MOUNT 178159
F3 FUSE 1A 250V SB 5X20 ULCSA IEC 089132
(F3) HOLDER FUSE 5X20MM PCB MOUNT 178159
F4 FUSE 1A 250V SB 5X20 ULCSA IEC 089132
(F4) HOLDER FUSE 5X20MM PCB MOUNT 178159
FN1 FILTER EMI 180057
HS1 HEATSINK TO-218 080020
HS2 HEATSINK TO220 080021
HS3 HEATSINK TO-220 080024
HS4 HEATSINK TO-218 080020
HS5 HEATSINK TO220 080021
HS6 HEATSINK TO220 080021
HS7 HEATSINK TO220 080021
J1 7 PIN SHROUDED HEADER 117910
J2 HEADER 9 CIRCUIT POST NATURAL 117724
J3 10 PIN SHROUDED HEADER 2MM 117973
J4 CONN FFC 18PIN 117908
K1 RELAY POWER TV5 12V 087070
K2 RELAY DPST 12VDC 087059
K3 RELAY DPST 12VDC 087059
WASHER SHLDR #10 BLK NYLN INS 104101
PCB1 PC BD POWER 129868
Q1 TRANSISTOR NPN SILICON 132317
Q2 TRANSISTOR NPN SILICON 132317
Q3 TRANSISTOR PNP 132263
R1 FUSE RESETTABLE 900mA 144733
R2 RES MF 1.82K 1% 1/4W 144582
R3 RES MF 1.82K 1% 1/4W 144582
R4 RES MF 22.1 OHM 1% 1/4W 144554
R5 RES MF 10K 1% 1/4W 144504
R6 RES MF 10K 1% 1/4W 144504
R7 RES MO 56.2 1% 1W 144695
R8 RES MF 10K 1% 1/4W 144504
R9 RES MF 249 OHM 1% 1/4W 144721
R10 RES MF 249 OHM 1% 1/4W 144721
R11 RES MF 10K 1% 1/4W 144504
R12 RES MF 1.21K 1% 1/4W 144566
U1 IC REGULATOR 1.8V 133673
(U1) SCR MS 4-40 X 3/8 PH PN BLK 400178
(U1) INSULATOR ISOSTRATE TO 220 084133
U2 IC REGULATOR 5V 133597
(U2) SCR MS 4-40 X 1/4 PH PN BLK 400121
(U2) NUT KEP 4-40 CLR 402001
U3 IC REGULATOR 3.3V 1.5A 133674
(U3) SCR MS 4-40 X 1/4 PH PN BLK 400121
(U3) NUT KEP 4-40 CLR 402001
U4 IC REGULATOR 5V 1.5A LOW DROP 133610
(U4) SCR MS 4-40 X 1/4 PH PN BLK 400121
U5 IC 12V REGULATOR LOW DROP 133611
(U5) SCR MS 4-40 X 1/4 PH PN BLK 400121
(U5) NUT KEP 4-40 CLR 402001
U6 IC REGULATOR 12V 133590
(U6) SCR MS 4-40 X 1/4 PH PN BLK 400121
(U6) NUT KEP 4-40 CLR 402001
U7 IC REGULATOR -12V 133574
(U7) INSULATOR ISOSTRATE TO 220 084133
(U7) SCR MS 4-40 X 1/4 PH PN BLK 400121
(U7) NUT KEP 4-40 CLR 402001
7
PRIMARY PCB 750614
(F1) HOLDER FUSE 5X20MM PCB MOUNT 178159
J1 CONN PCB MOUNT POWER RED 117719
J2 CONN PCB MOUNT POWER RED 117719
J3 CONN PCB MOUNT POWER RED 117719
J4 CONN PCB MOUNT POWER RED 117719
J5 BLADE FASTON W/FEET 117708
J6 BLADE FASTON W/FEET 117708
PC BD PRIMARY 129803
8
HEADPHONE PCB 750296
C1 CAP MONO .1UF 50V 20% Z5U 061346
J1 HEADPHONE JACK 1/4 117881
J2 CONN 4 PIN 117215
PC BD HEADPHONE 129717

McIntosh MCD301 Specifications

General

Frequency range	4 - 40000 Hz
Audio formats supported	MP3
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.002 %
CD-RW playback	Yes
Playback disc formats	CD audio, SACD
CD changer	No
Device type	Personal CD player
Product color	Black
Channels quantity	2 channels
Disc loading type	Tray
Number of optical discs	1 discs
Remote control type	IR

Weight and Dimensions

Depth	419.1 mm
Width	444.5 mm
Height	152.4 mm
Weight	12800 g
