McIntosh MCD350 User Manual

10
MCD350 Connections
The MCD350 has the ability to be remotely switched
On/Off from a McIntosh Integrated Amplifier or
Preamplifier via the Power Control connection. The
MCD350 Data Port Connection allows for the re-
mote operation of basic functions using the McIntosh
Integrated Amplifier or Preamplifier Remote Control.
With an external sensor connected to the MCD350, re-
mote control operation is possible from another room
and/or when the MCD350 is located in a cabinet with
the doors closed.
The connection instructions below, together with
the MCD350 Connection Diagram on the opposite
page is an example of a typical audio system. Your
system may vary from this, however the actual com-
ponents would be connected in a similar manner. For
additional information refer to “Connector and Cable
Information” on page 4.
Power Control Connections:
1. Connect a Control Cable from the Integrated Am-
plifier or Preamplifier Power Control MAIN (or
ACC) Jack to the POWER CONTROL IN Jack on
the McIntosh MCD350 SACD/CD Player.
2. Optionally, connect a Control Cable from the
MCD350 SACD/CD Player POWER CONTROL
OUT Jack to another component with a Power
Control In Jack.
Data Control Connections:
3. Connect a Control Cable from the Integrated
Amplifier or Preamplifier Data Port 3 Jack to the
McIntosh MCD350 SACD/CD Player DATA IN
Jack.
Sensor Connections:
4. Optionally, connect an IR Sensor to the McIntosh
MCD350 SACD/CD Player IR IN Jack.
Analog Audio Connections:
5. Connect Balanced Cables from the McIntosh
MCD350 SACD/CD Player AUDIO OUTPUT
BALANCED Connectors to the Integrated Ampli-
fier or Preamplifier Balanced Input Jacks.
6. Optionally, connect an Audio Cable from the
MCD350 SACD/CD Player AUDIO OUTPUT,
UNBALANCED Jacks to the Integrated Amplifier
or Preamplifier Unbalanced Input Jacks.
Digital Audio Connections:
7. Optionally, connect a Cable from the McIntosh
MCD350 SACD/CD Player DIGITAL AUDIO
OUTPUT (COAXIAL or OPTICAL) to the Opti-
cal or Coaxial Input on the Integrated Amplifier
or Preamplifier.
AC Power Cords Connections:
8. Connect the McIntosh MCD350 SACD/CD Player
AC Power Cord to a live AC outlet.
