11
Front Panel Controls, Displays, Push-Buttons, and Switch
Main Switch turns
all AC power com-
pletely On or Off
Selects various Digital
Sources for listening
This Push-button with indicator, activates
the Setup Mode. Setup allows the chang-
ing of the Input Titles, Volume Setting
and the Display Bightness from the de-
fault settings.
Adjusts the listening
volume level and also
selects various setup
functions
IR Sensor for
Remote Con-
trol Operation
Switches the MDA1000
On or Off (Standby). The
LED Indicator illumi-
nates when there is in-
coming AC Power
Indicates the Sources,
Volume Levels, Opera-
tional Functions and
Setup Mode Settings
