18
ACZ 010A through 039A IOMM ACZ1
Table 6, ACZ 010A – 039A Compressor and Condenser Fan Motor Amp Draw
Rated Load Amps Locked Rotor Amps
Compressors Compressors
Across-The-Line
ACZ
Unit
Size
Volts Hz.
No. 1 No. 2
Fan
Motor
(Each)
No. of
Fan
Mtrs
Fan
Motor
(Each)
No. 1 No. 2
208 13.5 13.5 5.8 2 23.7 115 115
230 13.5 13.5 5.8 2 21.4 115 115
460 7.0 7.0 2.8 2 10.7 47.5 47.5
010A
575
60
5.0 5.0 3.0 2 11.5 37.5 37.5
208 18.6 18.6 5.8 2 23.7 156 156
230 18.6 18.6 5.8 2 21.4 156 156
460 9.0 9.0 2.8 2 10.7 75 75
013A
575
60
7.4 7.4 3.0 2 11.5 54 54
208 23.7 23.7 5.8 2 23.7 189 189
230 23.7 23.7 5.8 2 21.4 189 189
460 12.5 12.5 2.8 2 10.7 99 99
016A
575
60
9.1 9.1 3.0 2 11.5 74 74
208 29.9 29.9 5.8 2 23.7 232 232
230 29.9 29.9 5.8 2 21.4 232 232
460 15.3 15.3 2.8 2 10.7 125 125
020A
575
60
11.6 11.6 3.0 2 11.5 100 100
208 33.6 41.0 5.8 3 23.7 278 350
230 33.6 41.0 5.8 3 21.4 278 350
460 16.5 21.8 2.8 3 10.7 127 158
025A
575
60
13.7 17.3 3.0 3 11.5 100 125
208 41.0 41.0 5.8 3 23.7 350 350
230 41.0 41.0 5.8 3 21.4 350 350
460 21.8 21.8 2.8 3 10.7 158 158
028A
575
60
17.3 17.3 3.0 3 11.5 125 125
208 52.6 52.6 5.8 3 23.7 425 425
230 52.6 52.6 5.8 3 21.4 425 425
460 23.7 23.7 2.8 3 10.7 187 187
033A
575
60
21.7 21.7 3.0 3 11.5 148 148
208 70 70 5.8 3 23.7 448 448
230 70 70 5.8 3 21.4 448 448
460 35 35 2.8 3 10.7 225 225
039A
575
60
28 28 3.0 3 11.5 180 180
See page 20 for all Electrical Data notes.
