18 AGR 070A through 100A IOMM AGR-1
Table 11, 60 Hz Single Point Power, Field Wiring Data
Wiring to Standard Wiring to Optional
Power Block Non-Fused Disconnect Switch
AGR
Unit
Size
Volts
Terminal
Amps
Connector Wire Range
(Copper Wire Only)
Terminal
Amps
Connector Wire Range
(Copper Wire Only)
208 335 # 4 - 400 MCM 400 250 - 500 MCM
230 335 # 4 - 400 MCM 400 250 - 500 MCM
380 335 # 4 - 400 MCM 250 #4 - 350 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
070AS
070AM
575 335 # 4 - 400 MCM 150 #2 - 3/0
208 840 (2 qty.) 1/0 - 600 MCM 400 250 - 500 MCM
230 335 # 4 - 400 MCM 400 250 - 500 MCM
380 335 # 4 - 400 MCM 250 #4 - 350 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
075AS
075AM
575 335 # 4 - 400 MCM 150 #2 - 3/0
208 840 (2 qty.) 1/0 - 600 MCM 400 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 400 250 - 500 MCM
380 335 # 4 - 400 MCM 250 #4 - 350 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
080AS
080AM
575 335 # 4 - 400 MCM 250 #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
380 335 # 4 - 400 MCM 400 250 - 500 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
085AS
085AM
575 335 # 4 - 400 MCM 250 #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
380 335 # 4 - 400 MCM 400 250 - 500 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
090AS
090AM
575 335 # 4 - 400 MCM 250 #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
380 335 # 4 - 400 MCM 400 250 - 500 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
095AS
095AM
575 335 # 4 - 400 MCM 250 #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
380 335 # 4 - 400 MCM 400 250 - 500 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
100AS
100AM
575 335 # 4 - 400 MCM 250 #4 - 350 MCM
All Electrical Data notes are on page 19.
