IM-FCU-0999
CONTENTS
- Safety Precautions page 02
- Installation Diagram page 03
- Outline And Dimensions (CC series) page 04
- Outline And Dimensions (CK series) page 04
- Outline And Dimensions (CE series) page 05
- Installation Of Indoor Unit page 05
- Electrical Wiring Connection page 11
- Overall Checking page 12
- Service And Maintenance page 12
- Trouble Shooting page 12
SAFETY PRECAUTIONS
Before installing the air conditioner unit, please read the following safety precautions carefully.
! Caution
Please take note on the following important points when installing.
• Do not install the unit where leakage of flammable gas may occur.
If water gas leaks and accumulates at the surrounding of the unit, it may cause fire ignition.
• Ensure that the drainage piping is connected properly.
If the drainage piping is not connected properly, it may cause water leakage which will dampen the
furniture.
• Ensure that the unit panel is covered back after service or installation.
Unsecured panel will cause the unit to operate noisily.
! Warning
• Installation and maintenance should be performed by qualified persons who are familiar with local code and
regulation, and experienced with this type of appliance.
• All field wiring must be installed in accordance with the national wiring regulation.
• Ensure that the rated voltage of the unit corresponds to that of the name plate before commencing wiring work
according to the wiring diagram.
• The unit must be GROUNDED to prevent possible hazard due to insulation failure.
• All electrical wiring must not touch the refrigerant piping or any moving parts of the fan motors.
• Confirm that the unit has been switched OFF before installing or servicing the unit.
IMPORTANT
DO NOT INSTALL OR USE THE AIR CONDITIONER UNIT IN A LAUNDRY ROOM.
IM-FCU-0999L (Eng) 7/14/00, 1:18 PM2
