ENGLISH
1. Transmission source
• The source where the signal will be transmitted.
2. Signal transmission indication
• Blink to confirm that the last setting has been transmitted to the unit.
3. “ON/OFF” Button
• Press once to start the air conditioner unit.
• Press again to stop the unit.
4. Fan speed selection
• Press the button continuously will toggle the fan speed in the following
order:
Low –––
:
Med –––
:
High –––
:
Auto
• Stop pressing when the desired fan speed appears on the display screen.
5. Operation mode
• Press the MODE button to select the type of operating mode.
• For cooling only unit, the available modes are: COOL ( ), DRY ( ) and
FAN ( ).
• For heat pump unit, the available modes are: AUTO ( ), COOL ( ),
DRY ( ), FAN ( ) and HEAT ( ).
• The AUTO ( ) mode is unavailable for chilled water system.
6. Automatic air swing
• Press the SWING button to activate the automatic air swing function.
• To distribute the air to a specific direction, press the SWING button and
wait until the louver move to the desired direction and press the button once
again.
Swing mode selection method (for CK-E model)
• Press SWING ( ) button for 4 seconds to enter field setting mode. While in
field setting mode, it will only show SWING MODE ( ).
• Press temperature and button to select SWING MODE ( ) rotation
from Swing Mode 1 to Swing Mode 3.
• There are 3 different SWING MODE, which are:
Swing mode 1 Swing mode 2 Swing mode 3
SWING MODE will not activate unless SWING is activated.
Swing is indicated by the logo:
• If no mode changes within 4 seconds, unit will operate according to the selected
SWING MODE ( ).
7. Turbo function (model dependent)
• Press for fast cooling or heating operation.
• Fan speed turn to maximum speed.
• Press again to deactivate the function.
• Available under HEAT, COOL and DRY modes only.
• Any change of fan speed will deactivate this function.
OPERATING GUIDE
Original Instruction
1 OM-GS01-1209(0)-McQuay 1/14/10, 4:37 PM1
