11
Once the thermostat is installed, it should be thoroughly tested.
CAUTION!:
Do not energize the air conditioning system when the outdoor temperature is below 50
degrees. It can result in equipment damage or personal injury.
Cool Test
1. Slide Mode switch to Cool mode.
2. Adjust set temperature so it is 5 degrees below room temperature.
3. Air conditioning should come on within a few seconds. Status indicator may come on.
4. Adjust the set temperature 2 degrees above the room temperature and the A/C should
turn off. There may be a fan delay on your system.
Heat Test
1. Slide Mode switch to Heat mode.
2. Adjust the set temperature so it is 5 degrees above the room temperature.
3. Heat should come on within a few seconds. Status indicator may come on.
4. Adjust the set temperature so it is 2 degrees below the room
temperature and the heat should turn off. There may be a fan delay on your system.
Cool Off Heat Auto
Cool Off Heat Auto
Fan Test
1. Slide Fan switch to On position.
2. Indoor fan turns on.
Auto
On
Auto
On
3. Slide Fan switch to Auto position.
4. Indoor fan turns off.
Testing the Thermostat
