Engineering Data - M5CKY - C Series (R410A model)
MODEL INDOOR UNIT M5CKY10CR M5CKY15CR M5CKY20CR
INDOOR UNIT
CONTROL
AIR DISCHARGE
4 WAY AUTOMATIC LOUVER
(UP & DOWN)
OPERATION
WIRELESS OR WIRED REMOTE
CONTROL
AIR FLOW
HIGH l/s / CFM 193 / 400 193 / 410 212 / 450
MEDIUM l/s / CFM 184 / 390 203 / 430
LOW l/s / CFM 170 / 360 193 / 410
SOUND PRESSURE LEVEL (H/M/L) dBA 44 / 43 / 42 44 / 42 / 41 47 / 46 / 44
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 250 x 570 x 570
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 317 x 630 x 630
UNIT WEIGHT kg 22 23
CONDENSATE DRAIN SIZE mm 19.1
FAN
TYPE TURBO
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE B
RATED INPUT POWER W 62 74
RATED RUNNING CURRENT A 0.28 0.31
MOTOR OUTPUT W 16 22
POLES 6
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7.00
FIN
MATERIAL
ALUMINIUM
(HYDROPHILIC FIN)
FACE AREA m
2
0.25
ROW 2
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR GREY
DRAWING NUMBER 0453103CS10 0453103CS15 0453103CS20
1) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
2) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
