M5MSY_(i) Engineering & Physical Data
Engineering & Physical Data
Engineering Data - M5MSY - B Series (R410A model)
MODEL
OUTDOOR UNIT M5MSY18BR M5MSY20BR M5MSY25BR M5MSY30BR
TYPE 1-to-2 1-to-3 1-to-4
NOMINAL COOLING CAPACITY
Btu/h 13650 (4400 ~15350) 18400 (5100 - 21200) 22200 (3400 - 26100) 26100 (4100 - 31000)
W 4000 (1300 ~ 4500) 5400 (1500 - 6200) 6500 (1000 - 7650) 7650 (1200 - 9100)
NOMINAL HEATING CAPACITY
Btu/h
15000 (2700 ~ 17400) 21800 (2400 - 23500) 25200 (3100 - 28000) 28700 (3100 - 30700)
W
4400 (800 ~ 5100) 6400 (700 - 6900) 7400 (900 - 8200) 8400 (900 - 9000)
NOMINAL TOTAL INPUT POWER (COOLING) W
1050 (330 ~ 1400) 1378 (380 ~ 1720) 1702 (400 ~ 2370) 2113 (430 ~ 2950)
NOMINAL TOTAL INPUT POWER (HEATING) W
1040 (250 ~ 1450) 1492 (270 ~ 1680) 1749 (350 ~ 2130) 2054 (380 ~ 2550)
NOMINAL RUNNING CURRENT (COOLING) A
4.82 (1.97 ~ 6.33) 6.15 (2.88 ~ 7.58) 7.58 (2.94 ~ 10.47) 9.30 (3.13 ~ 12.91)
NOMINAL RUNNING CURRENT (HEATING) A
4.76 (1.45 ~ 6.50) 6.62 (2.03 ~ 7.46) 7.72 (2.59 ~ 9.41) 8.98 (2.70 ~ 11.16)
EER W/W
3.81 3.91 3.82 3.62
COP W/W
4.23 4.28 4.23 4.09
REFRIGERANT CHARGE kg
1.20 2.00 2.6
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50
REFRIGERANT TYPE
R410A
OUTDOOR UNIT
AIR FLOW l/s / CFM 512/1076 780 / 1638 850 / 1786
SOUND PRESSURE LEVEL dBA 47 48 49
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 550 x 765 x 285 756 x 855 x 328
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 610 x 895 x 360 793 x 990 x 415
UNIT WEIGHT kg 34 45 55
PIPE
CONNECTION
TYPE FLARE
SIZE
LIQUID mm 2 x 6.35 3 x 6.35 4 x 6.35
GAS mm 2 x 9.52 2 x 12.7
1 x 9.52
2 x 12.7
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE DC BRUSHLESS
INDEX OF PROTECTION (IP) IP23 IP34
INSULATION GRADE Class E
RATED INPUT POWER W 35 61 79
RATED RUNNING CURRENT A 0.38 0.73 0.91
MOTOR OUTPUT W 50 61
COMPRESSOR
TYPE HERMATIC SWING COMPRESSOR
OIL TYPE DAPHNE FVC50K POLYESTER OIL (PVE)
OIL AMOUNT cm
3
450 650 750
RATED INPUT POWER (COOLING) W - 1183 1420
RATED INPUT POWER (HEATING) W - 1264 1491
RATED RUNNING CURRENT
(COOLING)
A - 4.69 6.7
RATED RUNNING CURRENT
(HEATING)
A - 4.09 5.58
COIL
TUBE
MATERIAL
INNER GROOVE
COPPER
SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7
FIN
MATERIAL
ALUMINIUM
(HYDROPHILIC FIN)
FACE AREA m
2
0.405 0.62
ROW 2
CASING COLOUR LIGHT GREY
DRAWING NUMBER 0453103CV18 0453103CV20 0453103CV25 0453103CV30
1) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
2) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
3) A5MSY18BR IS APPLICABLE WITH 5WMY10/15 LR BUT NOT WITH 5WMY10/15 JR (FOR WM UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
