Engineering Data - M5WMY - L Series (R410A model)
MODEL INDOOR UNIT M5WMY10LR M5WMY15LR
INDOOR UNIT
CONTROL
AIR DISCHARGE
AUTO LOUVER (UP & DOWN) & GRILLE
(LEFT & RIGHT)
OPERATION WIRELESS REMOTE CONTROL
AIR FLOW
TURBO l/s / CFM 178 / 378 185 / 392
HIGH l/s / CFM 163 / 345 169 / 358
MEDIUM l/s / CFM 128 / 272 133 / 282
LOW l/s / CFM 101 / 215 109 / 232
QUIET l/s / CFM 78 / 165 78 / 165
SOUND PRESSURE LEVEL (SH/H/M/L/SL) dBA 41 / 40 / 34 / 29 / 21 42 / 41 / 34 / 30 / 22
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 288 X 800 X 206
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 350 x 894 x 280
UNIT WEIGHT kg 9
CONDENSATE DRAIN SIZE mm 19
FAN
TYPE CROSS FLOW FAN
DRIVE DIRECT
FAN MOTOR
TYPE 1-phase SCR
INDEX OF PROTECTION (IP) IP44
INSULATION GRADE E
RATED INPUT POWER W 34 42
RATED RUNNING CURRENT A 0.19 0.21
MOTOR OUTPUT W 18
POLES 4
COIL
TUBE
MATERIAL COPPER INNER GROOVE
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM (HYDROPHILIC FIN)
FACE AREA m
2
0.18
ROW 2
AIR QUALITY FILTER
TYPE BIO AND TITANIUM APATITE FILTER
QUANTITY pc 2
CASING COLOUR WHITE
DRAWING NUMBER 0453103CW10 0453103CW15
1) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
2) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
