M5MSY_(i) Engineering & Physical Data
Engineering Data - M5WMY - J Series (R410A model)
MODEL INDOOR UNIT M5WMY10JR M5WMY15JR M5WMY20JR
INDOOR UNIT
CONTROL
AIR DISCHARGE AUTO LOUVER (UP & DOWN) & GRILLE (LEFT & RIGHT)
OPERATION WIRELESS REMOTE CONTROL
AIR FLOW
TURBO l/s / CFM 178 / 378 185 / 392 273 / 578
HIGH l/s / CFM 163 / 345 169 / 358 250 / 529
MEDIUM l/s / CFM 128 / 272 133 / 282 222 / 471
LOW l/s / CFM 101 / 215 109 / 232 197 / 418
QUIET l/s / CFM 86 / 182 86 / 182 177 / 374
SOUND PRESSURE LEVEL (SH/H/M/L/SL) dBA 41 / 40 / 34 / 29 / 25 42 / 41 / 34 / 30 / 28 44 / 42 / 39 / 36 / 33
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 288 x 800 x 206 310 x 1065 x 224
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 350 x 894 x 280 370 x 1121 x 285
UNIT WEIGHT kg 9 14
CONDENSATE DRAIN SIZE mm 19 19.1
FAN
TYPE CROSS FLOW FAN
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP44
INSULATION GRADE E
RATED INPUT POWER W 34 42 60
RATED RUNNING CURRENT A 0.19 0.21 0.27
MOTOR OUTPUT W 18 26
POLES 4
COIL
TUBE
MATERIAL COPPER INNER GROOVE
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM (HYDROPHILIC FIN)
FACE AREA m
2
0.18 0.29
ROW 2
AIR QUALITY FILTER
TYPE SARANET FILTER
QUANTITY pc 2
CASING COLOUR WHITE
DRAWING NUMBER 0453103CX10 0453103CX15 0453103CX20
1) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
2) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
