M5MSY_(i) Engineering & Physical Data
Engineering Data - M5CCY - C Series (R410A model)
MODEL INDOOR UNIT M5CCY10CR M5CCY15CR M5CCY20CR
INDOOR UNIT
CONTROL
AIR DISCHARGE DUCTED
OPERATION WIRELESS OR WIRED REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 172 / 365 194 / 410 269 / 570
MEDIUM l/s / CFM 160 / 340 175 / 370 255 / 540
LOW l/s / CFM 137 / 290 118 / 250 213 / 450
EXTERNAL STATIC PRESSURE (H/M/L)
Pa (in.wg.)
29 / 25 / 19 29 / 20 / 10
SOUND PRESSURE LEVEL (H/M/L) dBA 35 / 32 / 26 37 / 34 / 29 38 / 36 / 34
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 261 x 765 x 411 261 x 1065 x 411
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 376 x 1091 x 541 376 x 1251 x 541
UNIT WEIGHT kg 21
CONDENSATE DRAIN SIZE mm 19.1
FAN
TYPE SIROCCO
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) - IP20
INSULATION GRADE B E B
RATED INPUT POWER W 89 100 133
RATED RUNNING CURRENT A 0.39 0.42 0.61
MOTOR OUTPUT W 40 50 80
POLES 4
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7.00
FIN
MATERIAL
ALUMINIUM
(HYDROPHILIC FIN)
FACE AREA m
2
0.13 0.16
ROW 3
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR WITHOUT POWDER PAINT
DRAWING NUMBER 0453113CT10 0453113CT15 0453113CT20
1) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
2) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
