Performance Data M5MSY_(i)
Model: M5MSY25BR
Cooling Mode
Combination of indoor unit *
Each capacity (kW) Total capacity (kW) Total input (W) EER Total current (A)
A room B room C room Rated Max Rated Max Rated Rated Max
10 2.50 --- --- 2.50 3.00 590 850 4.24 2.70 3.80
15 3.50 --- --- 3.50 3.70 910 960 3.85 4.10 4.20
20 --- --- 5.00 5.00 5.80 1700 2200 2.94 7.50 9.70
10 + 10 2.50 2.50 --- 5.00 5.90 1580 2000 3.16 7.00 8.80
10 + 15 2.46 3.44 --- 5.90 6.40 2060 2370 2.86 9.10 10.40
10 + 20 2.17 --- 4.33 6.50 7.00 2300 2750 2.83 10.10 12.10
15 + 15 3.11 3.11 --- 6.22 7.40 2250 3190 2.76 9.90 14.10
15 + 20 2.62 --- 3.75 6.37 7.40 2300 3200 2.77 10.30 14.20
20 + 20 --- 3.22 3.22 6.44 7.80 1850 2930 3.48 8.30 12.90
10 + 10 + 10 2.16 2.16 2.16 6.48 7.80 2200 2750 2.95 9.70 12.10
10 + 10 + 15 1.91 1.91 2.68 6.50 7.90 2120 2800 3.07 9.40 12.20
10 + 10 + 20 1.63 1.63 3.24 6.50 8.10 1880 2900 3.46 8.30 12.80
10 + 15 + 15 1.68 2.36 2.36 6.40 8.00 2030 2650 3.15 8.90 11.70
10 + 15 + 20 1.48 2.07 2.95 6.50 8.40 1702 2800 3.82 7.60 12.30
15 + 15 + 15 2.16 2.16 2.16 6.48 8.00 2000 2900 3.24 9.00 12.70
* Applicable for indoor size 15 using Ø9.52mm gas pipe
Cooling Mode
Combination of indoor unit *
Each capacity (kW) Total capacity (kW) Total input (W) EER Total current (A)
A room B room C room Rated Max Rated Max Rated Rated Max
10 + 15 2.50 3.50 --- 6.00 6.40 2060 2370 2.91 9.10 10.40
15 + 15 3.22 3.22 --- 6.44 7.40 2250 3190 2.86 9.90 14.10
15 + 20 2.68 --- 3.82 6.50 7.40 2300 3200 2.83 10.30 14.20
10 + 10 + 15 1.91 1.91 2.68 6.50 7.90 2120 2800 3.07 9.40 12.20
10 + 15 + 15 1.70 2.40 2.40 6.50 8.00 2030 2650 3.20 8.90 11.70
10 + 15 + 20 1.48 2.07 2.95 6.50 8.40 1702 2800 3.82 7.60 12.30
15 + 15 + 15 2.16 2.16 2.16 6.48 8.00 1900 2900 3.41 8.50 12.70
* Applicable for indoor size 15 using Ø12.70mm gas pipe
Note : It is not recommended to connect the multi-split outdoor to single indoor only.
Heating Mode
Combination of indoor unit *
Each capacity (kW) Total capacity (kW) Total input (W) COP Total current (A)
A room B room C room Rated Max Rated Max Rated Rated Max
10 3.00 --- --- 3.00 4.00 1030 1370 2.91 4.70 6.10
15 3.80 --- --- 3.80 4.50 1420 1610 2.68 6.50 7.10
20 --- --- 5.60 5.60 5.70 1840 2260 3.04 8.40 9.90
10 + 10 3.60 3.60 --- 7.20 7.50 2240 2560 3.21 9.90 11.20
10 + 15 3.08 4.32 --- 7.40 7.90 2120 2580 3.49 9.40 11.30
10 + 20 2.47 --- 4.93 7.40 8.60 2050 2700 3.61 9.00 11.80
15 + 15 3.66 3.66 --- 7.32 8.60 2300 3000 3.18 10.20 13.20
15 + 20 3.05 --- 4.35 7.40 8.60 2040 2650 3.63 9.00 11.60
20 + 20 --- 3.66 3.66 7.32 8.60 1860 2680 3.94 8.30 11.80
10 + 10 + 10 2.46 2.46 2.46 7.38 8.40 1870 2750 3.95 8.20 12.10
10 + 10 + 15 2.18 2.18 3.04 7.40 8.40 1860 2720 3.98 8.20 11.90
10 + 10 + 20 1.85 1.85 3.70 7.40 8.60 1800 2660 4.11 8.00 11.60
10 + 15 + 15 1.94 2.73 2.73 7.40 8.40 2090 2680 3.54 9.30 11.70
10 + 15 + 20 1.68 2.36 3.36 7.40 8.60 1749 2500 4.23 7.80 10.90
15 + 15 + 15 2.46 2.46 2.46 7.38 8.40 1850 2700 3.99 8.10 11.80
* Applicable for indoor size 15 using Ø9.52mm and Ø12.70mm gas pipe
Note : It is not recommended to connect the multi-split outdoor to single indoor only.
