Engineering & Physical Data M5MSY-2010
General Data - Heat pump
MODEL INDOOR UNIT M5CKY 20ER M5CKY 25ER
CONTROL
AIR DISCHARGE 4 WAY AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS OR WIRED REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 283 / 600 321 / 680
MEDIUM l/s / CFM 250 / 530 283 / 600
LOW l/s / CFM 203 / 430 250 / 530
SOUND PRESSURE LEVEL (H/M/L) dBA 34 / 31 / 28 37 / 34 / 31
UNIT DIMENSION
(WITH PANEL)
HEIGHT mm/in 265 (340) / 10.4 (13.4) 265 (340) / 10.4 (13.4)
WIDTH mm/in 820 (990) / 32.3 (39.0) 820 (990) / 32.3 (39.0)
DEPTH mm/in 820 (990) / 32.3 (39.0) 820 (990) / 32.3 (39.0)
PACKING DIMENSION
(WITH PANEL)
HEIGHT mm/in 335 (410) / 13.2 (16.1) 335 (410) / 13.2 (16.1)
WIDTH mm/in 900 (1070) / 35.4 (42.1) 900 (1070) / 35.4 (42.1)
DEPTH mm/in 900 (1070) / 35.4 (42.1) 900 (1070) / 35.4 (42.1)
UNIT WEIGHT (UNIT + PANEL) kg/lb 29 + 6.0 / 64 + 13.2 29 + 6.0 / 64 + 13.2
CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75 19.1 / 0.75
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
MODEL UNIT NAME M5CCY 10CR M5CCY 15CR M5CCY 20CR M5CCY 25CR
INDOOR UNIT
AIR DISCHARGE DUCTED
OPERATION WIRELESS OR WIRED REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 172 / 365 194 / 410 269 / 570 326 / 690
MEDIUM l/s / CFM 160 / 340 175 / 370 255 / 540 302 / 640
LOW l/s / CFM 137 / 290 118 / 250 213 / 450 245 / 520
EXTERNAL STATIC PRESSURE
(H/M/L)
Pa / mmAq
29 / 25 / 19
(0.12 / 0.10 / 0.08)
29 / 20 / 10
(0.12 / 0.08 / 0.04)
29 / 20 / 10
(0.12 / 0.08 / 0.04)
29 / 20 / 10
(0.12 / 0.08 / 0.04)
SOUND PRESSURE LEVEL (H/M/L) dBA 35 / 32 / 26 37 / 34 / 29 38 / 36 / 34 40 / 39 / 36
UNIT DIMENSION
HEIGHT mm/in 261 / 10.3 261 / 10.3 261 / 10.3 261 / 10.3
WIDTH mm/in 765 / 30.1 765 / 30.1 1065 / 41.9 1200 / 47.2
DEPTH mm/in 411 / 16.2 411 / 16.2 411 / 16.2 411 / 16.2
PACKING DIMENSION
HEIGHT mm/in 376 / 14.8 376 / 14.8 376 / 14.8 376 / 14.8
WIDTH mm/in 1091 / 43.0 1091 / 43.0 1251 / 49.3 1386 / 54.6
DEPTH mm/in 541 / 21.3 541 / 21.3 541 / 21.3 541 / 21.3
UNIT WEIGHT kg/lb 21 / 9.5 21 / 9.5 9.5 / 21 11.3 / 25
CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75 19.1 / 0.75 19.1 / 0.75 19.1 / 0.75
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
