M5MSY-2010 Performance Data
Performance Data
Model: M5MSY20BR
Cooling Mode
Combination of indoor unit
Each capacity (kW) Total capacity (kW) Total input (W)
EER
Total current (A)
A room B room Rated Max Rated Max Rated Max
10 2.50 --- 2.50 3.00 620 800 4.03 2.80 3.60
15 3.50 --- 3.50 3.70 980 1280 3.57 4.30 5.60
20 --- 5.00 5.00 5.80 1620 2100 3.09 7.10 9.20
10 + 10 2.50 2.50 5.00 5.80 1470 1910 3.40 6.40 8.40
10 + 15 2.17 3.03 5.20 6.00 1550 2140 3.35 6.90 9.40
10 + 20 1.75 3.45 5.20 6.00 1500 2070 3.47 6.60 9.10
15 + 15 2.60 2.60 5.20 6.00 1400 2140 3.71 6.20 9.40
15 + 20 2.22 3.18 5.40 6.20 1378 1720 3.92 6.10 7.60
Heating Mode
Combination of indoor unit
Each capacity (kW) Total capacity (kW) Total input (W)
COP
Total current (A)
A room B room Rated Max Rated Max Rated Max
10 3.00 --- 3.00 4.00 1000 1260 3.00 4.50 5.60
15 3.80 --- 3.80 4.50 1250 1680 3.04 5.60 7.50
20 --- 5.60 5.60 6.50 1850 2510 3.03 8.20 11.00
10 + 10 3.00 3.00 6.00 6.50 1570 2150 3.82 6.90 9.50
10 + 15 2.54 3.56 6.10 6.50 1640 2000 3.72 7.20 8.80
10 + 20 2.03 4.07 6.10 6.70 1600 1800 3.81 7.00 7.90
15 + 15 3.05 3.05 6.10 6.50 1600 1970 3.81 7.00 8.70
15 + 20 2.64 3.76 6.40 6.90 1492 1680 4.29 6.60 7.50
Note : It is impossible to connect the indoor unit to 1 room only
