M5MSY-2010 Engineering & Physical Data
Engineering & Physical Data
General Data - Heat pump
MODEL INDOOR UNIT M5WMY 10JR M5WMY 15JR M5WMY 20JR M5WMY 25JR
INDOOR UNIT
AIR DISCHARGE 4 WAY AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 153 / 324 160 / 337 250 / 529 309 / 654
MEDIUM l/s / CFM 119 / 252 124 / 262 222 / 471 276 / 585
LOW l/s / CFM 93 / 197 101 / 213 197 / 418 239 / 507
SOUND PRESSURE LEVEL (H/M/L) dBA 40 / 34 / 29 41 / 34 / 30 41 / 39 / 35 44 / 41 / 37
UNIT DIMENSION
HEIGHT mm/in 288 / 11.3 288 / 11.3 310 / 12.2 310 / 12.2
WIDTH mm/in 800 / 31.5 800 / 31.5 1065 / 42.0 1065 / 42.0
DEPTH mm/in 204 / 8.0 204 / 8.0 224 / 8.8 224 / 8.8
PACKING DIMENSION
HEIGHT mm/in 350 / 13.8 350 / 13.8 386 / 15.2 386 / 15.2
WIDTH mm/in 894 / 35.2 894 / 35.2 1136 / 44.7 1136 / 44.7
DEPTH mm/in 280 / 11.0 280 / 11.0 285 / 11.2 285 / 11.2
UNIT WEIGHT kg/lb 9 / 19.9 9 / 19.9 6.3 / 14 6.3 / 14
CONDENSATE DRAIN SIZE mm/in 16 / 0.63 16 / 0.63 19.1 / 0.75 19.1 / 0.75
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
MODEL INDOOR UNIT M5CKY 10CR M5CKY 15CR M5CKY 20CR
CONTROL
AIR DISCHARGE 4 WAY AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS OR WIRED REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 193 / 400 193 / 410 212 / 450
MEDIUM l/s / CFM 184 / 390 184 / 390 203 / 430
LOW l/s / CFM 170 / 360 170 / 360 193 / 410
SOUND PRESSURE LEVEL (H/M/L) dBA 44 / 43 / 42 44 / 42 / 41 47 / 46 / 44
UNIT DIMENSION
(WITH PANEL)
HEIGHT mm/in 250 (295) / 9.8 (11.6) 250 (295) / 9.8 (11.6) 250 (295) / 9.8 (11.6)
WIDTH mm/in 570 (640) / 22.4 (25.2) 570 (640) / 22.4 (25.2) 570 (640) / 22.4 (25.2)
DEPTH mm/in 570 (640) / 22.4 (25.2) 570 (640) / 22.4 (25.2) 570 (640) / 22.4 (25.2)
PACKING DIMENSION
(WITH PANEL)
HEIGHT mm/in 317 (127) / 12.5 (5.0) 317 (127) / 12.5 (5.0) 317 (127) / 12.5 (5.0)
WIDTH mm/in 630 (700) / 24.8 (27.6) 630 (700) / 24.8 (27.6) 630 (700) / 24.8 (27.6)
DEPTH mm/in 630 (700) / 24.8 (27.6) 630 (700) / 24.8 (27.6) 630 (700) / 24.8 (27.6)
UNIT WEIGHT (UNIT + PANEL) kg/lb 22 + 2.0 / 49 + 4.0 23 + 2.0 / 51 + 4.0 23 + 2.0 / 51 + 4.0
CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75 19.1 / 0.75 19.1 / 0.75
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
