McQuay M5MSY20BR

53
Engineering & Physical Data M5MSY-2010
Components Data - Heatpump
MODEL UNIT NAME M5MSY20BR M5MSY25BR M5MSY30BR
OUTDOOR FAN
TYPE PROPELLER
QUANTITY 1
MATERIAL POLYPROPYLENE + GLASS FIBER + MICA
DRIVE DIRECT
DIAMETER mm/in 455 / 18
OUTDOOR FAN MOTOR
TYPE DC BRUSHLESS
QUANTITY 1
INDEX OF PROTECTION (IP) IP23
COMPRESSOR
TYPE HERMATIC SWING COMPRESSOR
OIL TYPE POLYESTER OIL (PVE)
OIL AMOUNT cm3 / fl .oz. 650 / 21.9
OUTDOOR COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm/in 7.00 / 0.276
THICKNESS mm/in 0.24 / 0.010
FIN
MATERIAL ALUMINIUM (HYDROPHILIC FIN)
THICKNESS mm/in 0.11 / 0.004
FACE AREA m2/ft2 0.62 / 6.67
ROW 2
FIN PER INCH 18 20
CASING OUTDOOR UNIT
MATERIAL GALVANISED MILD STEEL
COLOUR LIGHT GREY
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
