M5MSY-2010 Engineering & Physical Data
General Data - Heat pump
MODEL
UNIT NAME M5MSY25BR
TYPE 1-to-3
NOMINAL COOLING CAPACITY (Min - Max)
Btu/h 22200 (3400 - 26100)
W 6500 (1000 - 7650)
NOMINAL HEATING CAPACITY (Min - Max)
Btu/h 25200 (3100 - 28000)
W 7400 (900 - 8200)
NOMINAL TOTAL INPUT POWER (COOLING) W 1702
NOMINAL TOTAL INPUT POWER (HEATING) W 1749
NOMINAL RUNNING CURRENT (COOLING) A 7.56
NOMINAL RUNNING CURRENT (HEATING) A 7.77
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50
EER W/W 3.82
COP W/W 4.23
REFRIGERANT TYPE R-410A
AIR FLOW l/s / CFM 850 / 1786
SOUND PRESSURE LEVEL dBA 49
UNIT DIMENSION
HEIGHT mm/in 756 / 29.7
WIDTH mm/in 855 / 33.6
DEPTH mm/in 348 / 13.7
PACKING DIMENSION
HEIGHT mm/in 793 / 31.2
WIDTH mm/in 990 / 39.0
DEPTH mm/in 415 / 16.3
UNIT WEIGHT kg/lb 55 / 121.2
PIPE CONNECTION
TYPE FLARE
SIZE
LIQUID mm/in 3 x 6.35 / 1/4
GAS mm/in
1 x 9.52 / 3/8
2 x 12.7 / 1/2
REFRIGERANT CHARGE kg/lb 2.6 / 5.74
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
