51
Engineering & Physical Data M5MSY-2010
Components Data - Heat pump
MODEL INDOOR UNIT M5CCY 10CR M5CCY 15CR M5CCY 20CR M5CCY 25CR
INDOOR FAN
TYPE SIROCCO
QUANTITY 2
MATERIAL GALVANISED STEEL
DRIVE DIRECT
DIAMETER mm/in 164 / 6.5 164 / 6.5 160 / 6.3 160 / 6.3
LENGTH mm/in 202 / 8.0 202 / 8.0 200 / 7.9 200 / 7.9
INDOOR FAN MOTOR
TYPE INDUCTION
QUANTITY 1
INDEX OF PROTECTION (IP) - - IP20 IP21
INDOOR COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm/in 7.00 / 0.276
THICKNESS mm/in 0.24 / 0.009
FIN
MATERIAL ALUMINIUM (HYDROPHILIC FIN)
THICKNESS mm/in 0.11 / 0.004
FACE AREA m2/ft2 0.13 / 1.43 0.13 / 1.43 0.16 / 1.76 0.19 / 2.03
ROW 3
FIN PER INCH 18
AIR QUALITY
FIL-
TER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING INDOOR UNIT
MATERIAL GALVANISED STEEL
FINISHING WITH PE INSULATION
COLOUR WITHOUT POWDER PAINT
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
