M5MSY-2010 Performance Data
Model: M5MSY30BR
Cooling Mode
Combination of indoor unit
Each capacity (kW)
Total capacity
(kW)
Total input (W)
EER
Total current (A)
A room B room C room D room Rated Max Rated Max Rated Max
10 2.50 --- --- --- 2.50 3.00 590 850 4.24 2.70 3.80
15 3.50 --- --- --- 3.50 3.70 910 960 3.85 4.10 4.20
20 --- --- 5.00 --- 5.00 5.80 1700 2200 2.94 7.50 9.70
10 + 10 2.50 2.50 --- --- 5.00 5.90 1580 2000 3.16 7.00 8.80
10 + 15 2.50 3.50 --- --- 6.00 6.40 2060 2370 2.91 9.10 10.40
10 + 20 2.17 --- 4.33 --- 6.50 7.00 2300 2750 2.83 10.10 12.10
15 + 15 3.45 3.45 --- --- 6.90 7.40 2650 3190 2.60 11.70 14.10
15 + 20 3.01 --- 4.29 --- 7.30 7.40 2600 3200 2.81 11.50 14.20
20 + 20 --- 3.75 3.75 --- 7.50 7.80 2490 2930 3.01 11.20 12.90
10 + 10 + 10 2.55 2.55 2.55 --- 7.65 7.80 2450 2750 3.12 10.90 12.10
10 + 10 + 15 2.25 2.25 3.15 --- 7.65 7.90 2430 2800 3.15 10.60 12.20
10 + 10 + 20 1.91 1.91 3.83 --- 7.65 8.10 2400 2900 3.19 10.50 12.80
10 + 15 + 15 2.01 2.82 2.82 --- 7.65 8.00 2400 2650 3.19 10.50 11.70
10 + 15 + 20 1.74 2.43 3.48 --- 7.65 8.40 2370 2800 3.23 10.50 12.30
15 + 15 + 15 2.55 2.55 2.55 --- 7.65 8.00 2200 2900 3.48 9.70 12.70
10 + 10 + 10 + 10 1.91 1.91 1.91 1.91 7.64 8.40 2200 2680 3.47 9.80 11.80
10 + 10 + 10 + 15 1.74 1.74 1.74 2.43 7.65 9.10 2113 2950 3.62 9.30 13.00
Heating Mode
Combination of indoor unit
Each capacity (kW)
Total capacity
(kW)
Total input (W)
COP
Total current (A)
A room B room C room D room Rated Max Rated Max Rated Max
10 3.00 --- --- --- 3.00 4.00 1030 1370 2.91 4.70 6.10
15 3.80 --- --- --- 3.80 4.50 1420 1610 2.68 6.50 7.10
20 --- --- 5.60 --- 5.60 5.70 1840 2260 3.04 8.40 9.90
10 + 10 3.60 3.60 --- --- 7.20 7.50 2240 2560 3.21 9.90 11.20
10 + 15 3.08 4.32 --- --- 7.40 7.90 2120 2580 3.49 9.40 11.30
10 + 20 2.80 --- 5.60 --- 8.40 8.60 2610 2700 3.22 11.60 11.80
15 + 15 4.22 4.22 --- --- 8.44 8.60 2920 3000 2.89 12.80 13.20
15 + 20 3.46 --- 4.94 --- 8.40 8.60 2600 2650 3.23 11.50 11.60
20 + 20 --- 4.22 4.22 --- 8.44 8.60 2340 2680 3.61 10.40 11.80
10 + 10 + 10 2.73 2.73 2.73 --- 8.19 8.40 2700 2750 3.03 11.80 12.10
10 + 10 + 15 2.41 2.41 3.38 --- 8.20 8.40 2550 2720 3.22 11.20 11.90
10 + 10 + 20 2.05 2.05 4.10 --- 8.20 8.60 2250 2660 3.64 9.90 11.60
10 + 15 + 15 2.16 3.02 3.02 --- 8.20 8.40 2330 2680 3.52 10.30 11.70
10 + 15 + 20 1.86 2.61 3.73 --- 8.20 8.60 2130 2500 3.85 9.40 10.90
15 + 15 + 15 2.73 2.73 2.73 --- 8.19 8.40 2300 2700 3.56 10.20 11.80
10 + 10 + 10 + 10 2.05 2.05 2.05 2.05 8.20 8.60 2200 2400 3.73 9.70 10.50
10 + 10 + 10 + 15 1.91 1.91 1.91 2.67 8.40 9.00 2054 2550 4.09 9.10 11.16
Note : It is impossible to connect the indoor unit to 1 room only
